01 — Overview

Brochures & Product Book

The company overview and the full product catalogue, available for download and in printed form.

Brochure
PDF

Brochure

The company-wide overview of our concealed shading systems. Available for download and in printed version.

Product Book (2025)
PDF

Product Book (2025)

Full product catalogue with boxes, trims and compatibility matrices.

Product Book (2025) — US Version
PDF

Product Book (2025) — US Version

US edition of the product book with imperial dimensions and regional motor compatibility.

02 — Product Reference

Datasheets

Technical datasheets for every Blindspace series and every supported Tracktrim motor/track combination.

03 — Specification Text

Specification Documents

Specification-writing reference documents for architects and construction specifiers.

04 — Revit & CAD

BIM Files

Revit-ready BIM families for the Blindspace concealed shading range and compatible Louvolite roller-blind systems.

Roller Blinds — Louvolite System 40 Roller — with Back Bracket
Roller Blinds

Louvolite System 40 Roller — with Back Bracket

Louvolite System 40 compact roller blind on a back-bracket mount. Lightweight 40 mm tube suited to residential and light-commercial fabrics, ideal for pairing with C Series recess boxes.

FileLouvolite_Systm40RllrWithBackBr.zip635.5 KB · Added 22 Apr 2026
Roller Blinds — Louvolite Roller Blind on 55 mm System — A6000 Series
Roller Blinds

Louvolite Roller Blind on 55 mm System — A6000 Series

Louvolite A6000 series roller blind on a 55 mm tube system. Heavy-duty configuration engineered for large openings, dim-out / blackout fabrics, and motorised integration inside S Series ceiling boxes.

FileLouvolite_RllrBlndOn55mmSystmWithA6000Sr.zip623.5 KB · Added 22 Apr 2026
Concealed Blind Boxes — Blindspace® S Series — Standard Box to Conceal Blinds
Concealed Blind Boxes

Blindspace® S Series — Standard Box to Conceal Blinds

Fully-concealed S Series aluminium blind box for seamless ceiling or wall integration. Hides any blind type, retracting it completely out of sight for a flawless architectural finish.

FileBlindspace_BlndspaceStndSSrsToConcealBlnd.zip680.8 KB · Added 22 Apr 2026
Concealed Blind Boxes — Blindspace® C Series — Custom Box to Conceal Blinds
Concealed Blind Boxes

Blindspace® C Series — Custom Box to Conceal Blinds

Retrofit-friendly C Series aluminium blind box providing partial concealment and easy service access. Ideal for projects with limited ceiling access while preserving a discreet architectural look.

FileBlindspace_BlndspaceCstmCSrsToConcealBlnd.zip953.4 KB · Added 22 Apr 2026
Trim & Finishing — Blindspace® TrackTrim — Recessed Curtain Tracks
Trim & Finishing

Blindspace® TrackTrim — Recessed Curtain Tracks

Precision-engineered aluminium trim profile that conceals gaps and light leaks around recessed curtain and blind tracks. Paintable finish for fully integrated, invisible detailing.

FileBlindspace_TracktrimToRecessCurtnTrcks.zip4.7 MB · Added 22 Apr 2026
05 — Drawings Library

Technical Drawings

Recommended box-size technical drawings (PDF + DWG) for concealed window shading across roller blinds, tensioned systems, curtain tracks and skylight applications.
